www.domo-elektro.be 31
FR
• Retirez la plaque de charnière de la porte. Retirez la goupille de la plaque de charnière et faites
pivoter la plaque sur 180°. Resserrez la goupille dans la plaque de charnière. Veillez à ce que le
pignon en plastique reste autour de la goupille.
,QVWDOODWLRQ
Door Reversibility
Left Aid-Closer on Upper Door x 1 Left Aid-Closer on Lower Door x 1
nscrew top hinge cover and disconnect connectors of door switch and harness.
2.Unscrew top hinge
3.Remove the pin with a screwdriver and filp the hinge bracket. Then refit the pin to hinge bracket
unscrew
screw
8
• Déplacez l’interrupteur de porte de la plaque de recouvrement de la charnière droite vers la
plaque de recouvrement de la charnière gauche qui se trouve dans le sachet d’accessoires
fourni. Pour retirer l’interrupteur de porte, vous devez maintenir son clapet situé au dos du
couvercle enfoncé.
,QVWDOODWLRQ
5.Detach cover in top of upper door and move harness from right side to left side, then replace the cover.
6.Move top left cover to right side
7. Take off the upper door, take out the screw from the middle hinge by cross screwdriver,
then take off the lower door.
4.Move door switch from right hinge cover to left hinge cover in accessary bag.
9
,QVWDOODWLRQ
5.Detach cover in top of upper door and move harness from right side to left side, then replace the cover.
6.Move top left cover to right side
7. Take off the upper door, take out the screw from the middle hinge by cross screwdriver,
then take off the lower door.
4.Move door switch from right hinge cover to left hinge cover in accessary bag.
9
,QVWDOODWLRQ
5.Detach cover in top of upper door and move harness from right side to left side, then replace the cover.
6.Move top left cover to right side
7. Take off the upper door, take out the screw from the middle hinge by cross screwdriver,
then take off the lower door.
4.Move door switch from right hinge cover to left hinge cover in accessary bag.
9
• Retirez le panneau de nition de la partie supérieure de la porte supérieure. Déplacez le câble
et le connecteur d’un côté vers l’autre. Replacez le panneau de nition.
,QVWDOODWLRQ
5.Detach cover in top of upper door and move harness from right side to left side, then replace the cover.
6.Move top left cover to right side
7. Take off the upper door, take out the screw from the middle hinge by cross screwdriver,
then take off the lower door.
4.Move door switch from right hinge cover to left hinge cover in accessary bag.
9
• Déplacez la plaque de recouvrement au-dessus du réfrigérateur de la gauche vers la droite.
,QVWDOODWLRQ
5.Detach cover in top of upper door and move harness from right side to left side, then replace the cover.
6.Move top left cover to right side
7. Take off the upper door, take out the screw from the middle hinge by cross screwdriver,
then take off the lower door.
4.Move door switch from right hinge cover to left hinge cover in accessary bag.
9
