32 www.domo-elektro.be
EN
1. Place the rear grill on the motor, making sure that the groove in the grill corresponds to the
tongue on the motor.
2. Secure the rear grille with the nut. Tighten in a clockwise direction.
3. Place the fan blades on top of the unit so that the groove in the fan blades corresponds to the
tongue on the motor.
4. Secure the fan blades with the cap. Tighten anticlockwise.
5. Place the grill on the fan so that the grill clicks on the rear grill. Screw the unit into place using
the small screw at the bottom of the grill.
6. Insert 1 part of the tube into the hole provided in the base. Use the supplied screw to screw it
into place on the underside of the base.
7. Screw the upper tube onto the lower tube.
8. Turn the motor section onto the tubes.
1 2
43 5
6 7 8
