EN
Installation Mini Heki S FL
6
6 Installation
A
6.1 Cutting out the hole
See fig. 2
6.2 Using the reinforcing rails
Supplementary to fig. 3
1. Before installation, check whether the roof hole needs reinforcing.
2. Remove the foam according to the width of the reinforcing rail (not in scope of
delivery) (A).
3. Fit the reinforcing rails (B).
6.3 Mounting the roof light
Supplementary to fig. 4
The scope of delivery contains a mounting frame, which is suitable for roof thick-
nesses of 23 – 42 mm or 43 – 60 mm:
• Roof thicknesses 23 – 42 mm: Ref. no. 9620008857
• Roof thicknesses 43 – 60 mm: Ref. no. 9620008880
1. Measure the roof thickness W.
2. Shorten the sleeves to size H (see table).
3. Use the screws with appropriate lengths (see table).
See fig. 5
➤ Check that the roof light has sufficient space around (approx. 1 to 2 mm) it in the
roof opening.
See fig. 6
➤ Clean the roof opening in the mounting area.
NOTICE! Damage hazard
If you do not have sufficient technical knowledge for installing the
components in vehicles, you should have a specialist install the roof
window in your vehicle.
DometicMiniHeki-S-FL_IOM_4445104092_EMEA24_202x-xx-xx.book Page 6 Thursday, July 6, 2023 2:00 PM
