6. Technical Data
minimum typical maximum
Power supply
AC
rated voltage 21,6 V
AC
24,0 V
AC
30 V
AC
current input 80 mA 85 mA 90 mA
current input (at switching moment) 1.000 mA
DC
rated voltage 21,6 V
DC
24,0 V
DC
26,4 V
DC
current input 35 mA 40 mA 45 mA
current input (at switching moment) 550 mA
Control input
DC
control voltage 21,6 V
DC
24,0 V
DC
26,4 V
DC
control current 1 mA
control pulse duration 60 ms
push-button bounce time 10 ms
Relay output
3 signal relays (toggle positions)
AC/
DC
voltage 24 V
rated current 1.000 mA
relay (remote tripping of RCCB)
AC
voltage 230 V
AC
250 V
AC
adjustable
fault response current I
Δn
30 mA 500 mA
switching duration 400 ms
Semiconductor outputs not short-circuit proof – series resistor needed!
status LED
voltage 21,6 V
DC
24,0 V
DC
26,4 V
DC
rated current 50 mA
Dupline (optional)
power consumption (DFA ) 5 mA
power consumption (Dupline) 350 µA
input channels 4
output channels 3
Terminals
type screw terminal with strain-relief clamp
terminal cross-section 0,4 mm Ø 2,5 mm²
tightening torque 0,6 Nm
Housing
type
distribution board housing in accordance with DIN 43880 for
mounting on DIN rail in accordance with DIN EN 60715
dimensions 72 x 85 x 58 (W x H x D in mm) / 4 module widths
material polyamide (PA)
