3.3. Product Specifications
Model: Alpha Series A2.6i
Source:
Light source type LED
LED type Black face
Brightness 1000nits
Optical:
Pixel pitch (horizontal) 2,6mm
Pixel pitch (vertical) 2,6mm
Cabinet resolution (horizontal) 192px
Cabinet resolution (vertical) 192px
Module resolution (horizontal) 96px
Module resolution (vertical) 96px
Viewing angle (horizontal) 160°
Viewing angle (vertical) 160°
Minimum viewing distance 3m
Contrast ratio 5000:1
Cabinet ratio 1:1
Transparency 0 %
Control and Programming:
Control system Novastar
Receiving card A5s PLUS
Screen refresh rate 3840Hz
Electrical Specifications and Connections:
Power supply 100–240 V AC 50/60 Hz
Power consumption 130W
Power consumption average 50W
Power connector In Power Pro Blue
Power connector Out Power Pro Grey
Data connector In ProCat
Data connector Out ProCat
Mechanical Specifications:
Cabinet width 500mm
Cabinet height 500mm
Cabinet depth 76mm
Module width 250mm
Module height 250mm
Weight 6kg
Screen curving angles -5° / 0° / 5° / 10°
IP rating IP20 (indoor use only)
Housing Magnesium die-cast
Product Properties:
Cooling Passive
Maintenance Front service / Rear service
Rigging:
Fixed mounting option M10
9
c
Product code: 101811
Alpha Series A2.6i
