4.6.1.2. Standing Installation
By the standing installation, the device is installed on top of a rigging bar.
To install the LED screen on top of a standing rigging bar, follow the steps below:
01) Remove the rigging eye(s) from the top of the rigging bar, as shown in Fig. 25.01)
Figure 25
02) Put the LED screen on top of the rigging bar, so that the fast-lock openings (11) on the bottom of the LED02)
screen fit in the fast-locks of the rigging bar, as shown in Fig. 26 and 27.
Figure 26 Figure 27
03) Turn lever (A) of the left locking mechanism (06) counterclockwise.03)
04) Push the spring-loaded fast-lock (B) of the left locking mechanism (06) on the rigging bar upwards and turn04)
it by 90°, as shown in Fig. 28 and 29.
Figure 28 Figure 29
19
