11
©
2022 DJI All Rights Reserved.
Specifcations
Weight Approx. 350 g (transmitter only, excl. antennas)
Dimensions 127×97×26 mm (excl. antennas)
Operating Frequency
[1]
2.4000-2.4835 GHz, 5.150-5.250 GHz, 5.250-5.350 GHz,
5.470-5.725 GHz, 5.725-5.850 GHz
Transmitter Power (EIRP)
2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC)
5.8 GHz: <33 dBm (FCC/SRRC), <14 dBm (CE)
5.1 GHz: <23 dBm (FCC/SRRC/CE/MIC)
5.2 GHz: <30 dBm (FCC), <23 dBm (SRRC/CE/MIC)
5.5 GHz: <30 dBm (FCC), <23 dBm (CE/MIC)
Power Consumption 11 W
Power Supply Voltage
External Power Input Port: 6-18 V
DC-In Port: 6-18 V
Output Voltage Power Output Port: 6-18 V
Working Time
[2]
3 hours 40 min
Input Video Format
3G SDI: YCbCr 4:2:2 10bit
HDMI: RGB 4:4:4
1080p23.98/24/25/29.97/30/50/59.94/60;
1080i50/59.94/60;
720p50/59.94/60
Output Video Format
3G SDI: YCbCr 4:2:2 10bit
1080p23.98/24/25/29.97/30/50/59.94/60;
1080i50/59.94/60;
720p50/59.94/60
Input Audio Format HDMI embedded
Output Audio Format PCM
Video Transmission System O3 Pro
Max Bitrate 40 Mbps
Latency 68 ms (1080p 60fps), 100 ms (1080p 24fps)
Video Coding Format H.264
Max Transmission Distance
6 km (FCC), 4 km (CE/SRRC/MIC)
(unobstructed, free of interference)
Max Communication Bandwidth 40 MHz
Operating Temperature -10° to 45° C (14° to 113° F)
[1] Due to local regulations, the 5.1/5.2/5.8GHz frequencies are prohibited in some countries and the
5.1/5.2GHz frequencies are only allowed for use indoors in some countries. 5.600-5.650 GHz is not used.
[2] Tested in a room temperature of 25° C (77° F) when powered by a fully charged WB37 Intelligent Battery
and used with the DJI High-Bright Remote Monitor.
