8
©
2022 DJI All Rights Reserved.
Linking
The video transmitter must be linked to the receiver device before use. The video transmission
system of the video transmitter oers Control mode and Broadcast mode, which use dierent
linking methods. Refer to the following section for instructions and linking status indicator
descriptions.
Control Mode
1. Power on the video transmitter. Press and hold the menu dial on the video transmitter until the
linking status indicator blinks red and green alternately, indicating that it is ready to link.
2. Power on the remote monitor. Tap to enter System Menu and then Connection Settings.
Select Control Mode, set the monitor as Control Monitor A or Control Monitor B, and tap Link
to Control Monitor A/B to enter linking status.
3. When linking is complete, the linking status indicator turns solid green and the remote monitor
will have a connected status.
Broadcast Mode
1. Power on the video transmitter. Press the menu dial on the video transmitter, turn the dial to
select Broadcast in the menu, enable Broadcast mode, and select channel.
2. Power on the remote monitor. Tap to enter System Menu and then Connection Settings.
Select Broadcast Mode and the monitor will automatically search for nearby devices with
Broadcast mode enabled. Tap a device to monitor and the live view from the corresponding
device will display on the remote monitor. Tap the camera number on the right side of the
screen to refresh the live view or switch between the monitored devices.
Refer to the Broadcast Mode Settings section for more information about the usage.
Linking Status Indicator
Linking Status Indicator Description
Solid red Device started, not connected.
Blinks red and green alternately Linking.
Solid green Successfully linked in Control mode. Wireless video
transmission is normal.
Broadcast mode enabled.
Blinks red Device malfunction. Contact DJI Support.
