Disclaimer

By using this product, you signify that you have read, understand, and accept the terms and conditions

of this guideline and all instructions at https://www.dji.com/power-expansion-battery-2000. EXCEPT AS

EXPRESSLY PROVIDED IN AFTER-SALES SERVICE POLICIES AVAILABLE AT HTTPS://WWW.DJI.COM/SERVICE/

POLICY, THE PRODUCT AND ALL MATERIALS AND CONTENT AVAILABLE THROUGH THE PRODUCT ARE

PROVIDED "AS IS" AND ON "AS AVAILABLE BASIS" WITHOUT WARRANTY OR CONDITION OF ANY KIND.

This product is not intended for children.

Usage

DJI

Power Expansion Battery 2000 can be connected to the power station to expand the battery capacity.

Figure A: Press once to check the remaining battery level.

Figure B1: Make sure the power station is updated to the latest firmware. Power off the device and

disconnect the power supply. Use the included expansion battery cable to connect the port

of the expansion battery to the SDC port of the power station. Press and hold the power

button of the power station, the expansion battery will be powered on when Eb-1 appears on

the display screen of the power station.

Figure B2: The power station supports connecting multiple expansion batteries.

1. Connect the port

of the expansion battery to the SDC port of the power station, or to

the port

of the previous expansion battery.

2. Connect the port

of the expansion battery to the port

of the next expansion

battery.

•

Users can link the power station to the DJI Home app and view the device information or modify

settings in the app.

•

DO NOT use the DJI Power SDC Fast Charge Cable to directly connect the expansion battery to the

Intelligent Flight Battery of the aircraft.

•

DO NOT touch the metal terminals on the ports. When powered off, clean the metal terminals with a

clean, dry cloth if there is any noticeable build up.

•

Place the device on a flat and stable surface when in use. Make sure the device is properly insulated

to prevent fire hazards. DO NOT block the heat dissipation vents of the device.

Specifications

Model DYS_2000EB

Temperature Discharging: -10° to 45° C (14° to 113° F)

Charging: 0° to 45° C (32° to 113° F)

Expansion Battery Port Input / Output: 40.0-58.4 V DC, max 60 A, max 3000 W

CHS

免责声明

使用本产品前，请仔细阅读并遵循本文及与本产品相关的所有安全与合规操作指引。使用本产品视为您已经阅读

并接受与本产品相关的全部条款。本产品不适合儿童使用。

使用

DJI

Power Expansion Battery 2000（简称“加电包”）可连接至 DJI Power 户外电源，以满足更大的用电需求。

图 A：

短按一次电量按键可查看加电包的剩余电量。

图 B1：

确保户外电源已升级至最新固件且设备已关机，并断开设备与电源的连接。使用包装内的加电包连接线，

将加电包接口

连接至户外电源的 SDC 接口。长按户外电源的电源按键，电源的显示屏出现 Eb-1，

MAX 24W MAX 140W

POWER 1000

CHARGE

1200

600

SDC

Lite

SDCSDC

POWER EXPANSION BATTERY 2000
