SPIRAL MACHINE
L10 / L22 / L33 / L42 / L53 / L62
pag. 12
2.2.4 Safety devices
The safety devices adopted are the following:
• no.1 mobile guard covering the bowl linked to a safety microswitch;
• no.1 fixed guard to protect the spiral movement parts;
• no.1 fixed guard to protect the moving parts of the bowl;
• no.1 fixed guard to protect the dangerous area between the bowl and the machine frame;
• no.1 safety microswitch to supervise the mobile guard covering the segregated bowl inside the machine
head;
• no.1 maintained action cycle start button.
• no.1 proximity sensor located between the bowl and the machine frame (only for machine models with
the tilting head and the removable bowl, see Figura 3 2).
Figure 2-2. Safety devices
2.2.5 Residual risks
From the risk analysis conducted, the residual risk concerning the inhalation of dust from flour was identified.
This residual risk was addressed with the obligation of the operator to use a protective mask.
Another source of risk can be generated by behaviours that are not permitted by the operator such as for
example the failure to use the P.P.E. reported in the paragraph 2.1.3.
Warning signs for the operator have been applied to the machine shown in Table 2.
Interlocked
guard
Fixed
guard
Fixed
guard
Fixed
guard
