www.dimplex.eu 2204/A EN-13
DX 512E, DX 520E, DX 530E English
6. Overload protector
For your safety, the heating device is equipped with
an overload protector. If the air circulation is inter-
rupted (e.g. due to the air grille being covered or
closed), the device switches off automatically.
In this case, the power supply to the heating device
should be disconnected for a few minutes (switch off
the fuse) to allow the device to cool down sufficiently.
Before recommissioning the device, resolve the rea-
sons for the overload protector being triggered.
7. Maintenance
The device must be disconnected from the mains and
allowed to cool down before maintenance.
Clean the outside of the device using a soft, damp
cloth. Do not use scouring powder or furniture polish as
this may damage the surface.
Dust which gathers inside the device can be removed
from the outside using a vacuum cleaner.
8. Faults
If the heating device is not emitting any heat, check
the following points:
Has the heating level been selected?
Has the controller been set to the desired temper-
ature?
Has the overload protector been triggered? See
chapter 5.
Has the fuse in the switch box tripped?
If you cannot remedy the fault, please contact your
electrical retailer. The retailer will require the product
number (E no.) and the production date (FD) of the de-
vice. This information is listed on the type plate.
9. Warranty
This product is supplied with a two-year warranty ac-
cording to our terms of guarantee.
10. Recycling
Do not dispose of the device with general
household waste. Take the device to the
available collection points at the end of its
service life.
11. Technical data
Order code Unit DX 512E DX 520E DX 530E
Connection voltage 1/N/PE 230-240 V ~ 50 Hz
Power consumption kW 1.2 2.0 3.0
Protection class I, with protective conductor
Degree of protection IP20
Heating levels kW 0.8 / 1.2 1.2 / 2.0 2.0 / 3.0
Heat output
Nominal heat output Pnom kW 1.2 2.0 3.0
Minimum heat output (guide value) Pmin kW 0.8 1.2 2.0
Maximum continuous heat output Pmax,c kW 1.2 2.0 3.0
Additional power consumption
At nominal heat output Elmax W 0.5 0.5 0.5
At minimum heat output Elmin W 0.5 0.5 0.5
In standby mode elSB W 0.5 0.5 0.5
Type of heat output/room temperature control
Electronic room temperature controller with week
program and adaptive control of start of heating
°C 5 - 30
Dimensions width x height x depth
(with / without wall bracket)
mm 585 x 383 x 123 / 104
710 x 383 x 123 /
104
Weight kg 3.8 3.8 4.5
Glen Dimplex Deutschland GmbH Phone: +49 9221 709 700
Am Goldenen Feld 18 Fax: +49 9221 709 701
95326 Kulmbach, Germany E-mail: elektroheizung@dimplex.de
