PRIVACY ON

ZONE NUM 0

ZONE DISP ON

H-POS 12

V-POS 2

H-SIZE 3

V-SIZE 3

Y LEVEL 10

CB LEVEL 10

CR LEVEL 10

TRANS 0

EXIT JUMP

PRIVACY

&910 .05* 13*73(# %/ '6/$ 4&5 &9*5

You can hide some parts of the screen for privacy masking. A total of 16 dierent privacy masking zones are available.

The cameras support square privacy masks or advanced polygon masks.

- ZONE NUM : Select the zone number between 0~15.

- ZONE DISP : Zone display ON/OFF

- H-POS : Move the Zone position Left or right. The higher the number, the zone will move to the right.

- V-POS : Move the Zone position up or down. The higher the number, the zone will move down.

- H-SIZE : Reset the zone‘s size horizontally. The higher the number, the right side panel will move further to the right.

- V-SIZE : Reset the zone’s size vertically. The higher the number, the bottom side panel will move further down.

- Y LEVEL : The higher the number, the brighter the color will appear.

- CR LEVEL : The higher the number, the more red tone will be added to the zone’s color.

The lower the number, the more green will be added to the zone’s color.

- CB LEVEL : The higher the number, the more red tone will be added to the zone’s color.

The lower the number, the more red will be added to the zone’s color.

* High CB Level + High CR Level = Pink

* High CB Level + Low CR Level = Sky Blue

* Low CB Level + High CR Level = Orange

- TRANS : Set the mask’s transparency level from 0~3. The default value is 0.

OSD Menu

_

Privacy

28
