1
LENS
MANUAL : Manual mode supports the xed board lens or the manual iris lens.
AUTO : AUTO mode sets the camera’s iris automatically.
Under the LENS sub-menu, you can adjust the following settings:
1. Level
Change the camera’s iris value manually. If AUTO is selected, this option is disabled.
Set the shutter speed to AUTO, Manual, or FLC (Flicker-less mode).
* If AUTO is selected, select from the following options :
- NORMAL: Set when the camera is installed in an indoor environment.
- DEBLUR: Set when the camera is installed in an outdoor environment.
* Select FLC if the camera is experiencing some ickering in the image.
The shutter speed will be set to 1/100 for NTSC, or 1/120 for PAL.
* If Manual is selected, set the shutter speed from the options :
- 1/30(1/25) ~ 1/30000.
LENS
LEVEL ___
BRIGHTNESS 10
SHUTTER AUTO
FOCUS ADJ OFF
RETURN
LENS AUTO
BACKLIGHT OFF
DRC OFF
DEFOG OFF
AGC 10
STARLIGHT X4
3D DNR HIGH
EXIT JUMP
EXPOSURE
&910 .05* 13*73(# %/ '6/$ 4&5 &9*5
2. Brightness
Adjust the camera’s brightness from 0~20. The higher the number, the brighter the image will appear.
4. Focus Adjustment
When on, the default level is set automatically by controlling lens focus and based on
the installation and environment circumstances.
3. Shutter
1
OSD Menu
_
Exposure
21
