User Manual – ALP222e
● Routing the physical input signals towards the corresponding outputs (ana IN 1 towards ana
OUT1, ana IN 2 towards ana OUT2, AES 3 IN towards AES3 OUT).
As a result, playback signals and input signals are mixed to the outputs.
Note that a gain is applied to each input signal towards the output.
● Routing the content of physical inputs towards the associated recording outputs, so that an
application can capture the input signals.
9.4 Display of GPIOs and control of GPOs
Click on the icon to access the view that displays the state of the card's GPIO, from which the
GPO can be activated/deactivated.
The state of GPI inputs is displayed on the left and the state of GPO outputs is displayed on the right.
To position the state of a GPO manually, click on the "STATE" switch matching this GPO to move it to
the desired position: Open or Close.
26
