User Manual for ALP-DANTE
Clocking considerations
● AES67 mode on a Dante device enables both IEEE 1588 Precision Time Protocol
(PTP) v1 and v2. A single clock domain must be created across both PTP v1 and v2
devices:
- Standard Dante devices support PTP v1 only
- AES67-enabled Dante devices support PTP v1 and PTP v2
- AES67 devices support PTP v2 only
● PTP v1 and v2 are not inter-compatible. One AES67-enabled Dante device will act
as the boundary clock between PTP v1 and v2, bridging the two clock domains
Enabling ALP-DANTE as Master for both Dante and AES67.
● Enable the Dante card “Preferred Master” status
● Disable “Preferred Master” for all Dante devices that have AES67 disabled.
● Disable “Sync to External” for all devices.
● Assign a PTPv2 priority level of between 128 and 255 for all non-Dante devices
If another AES67 device (Grandmaster Clock, or another AES67 device) is the Master ,
● Make sure the PTP v2 Master has a priority of between 1 and 100, and is
using the “Media Profile” clock settings.
● Disable “Preferred Master” and “Sync To External” for all Dante devices.
One AES67-enabled Dante device will automatically be selected as the
Boundary clock, becoming the Dante Master.
● Make sure the Master Clock device is set to use the “Media profile” (not the
“Default profile” because Dante devices do not support the Default profile.
37
