User Manual for ALP-DANTE
9.3 Input and output vu-meters
Click on the icon to access the "I/O Monitor" view.
This view displays the vu-meters for all input and output channels.
Input vu-meters reflect the audio modulation received from the Dante streams routed to the
ALP-DANTE card. These are the channels to be acquired from the software application via the
recording devices.
Output vu-meters reflect the audio modulation received by the card from each software playback
device. Note that the output modulation is displayed even if the Dante network is disconnected.
The following table lists the various possible settings from the mixer view.
Vu-meters
Each Vu-meter displays the input signal peak-meters in dBfs.
Note that there is no clipping information that is reported. As a
consequence, the clipping threshold adjustment that can be found
from “Settings-> Audio meters” has no effect.
Click on this icon to display the concerned pair of channels as two mono
channel strips.
22
