DWL-5x000XY DATA SHEET
Mode (1 byte) : Mode Selection command
The data to be received from the tilt sensor module is as follow:
Source/Destination Stand/Mode Data CRC16
1 Byte 1 Byte 8 Bytes 2 Bytes
Source (4 bits) : Sender command
Destination (4 bits) : Receiver command
Stand (4 bits) : Position in either Single or Dual Axis
Mode (4 bits) : Mode Selection command
Data (8 bytes) : Received data
7.3. Commands for Source and Destination
Both the source and destination have the same command as listed below:
Command Descriptions
0x01 Sensor 1
0x02 Sensor 2
0x03 Sensor 3
0x04 Sensor 4
0x05 All sensor
0x06 Computer
0x07 Control Box
i.e. Command for selection of Single Axis Mode from Computer to Control Box:
Byte[0] Byte[1] Byte[2] Byte[3] Byte[4] Byte[5] Byte[6] Byte[7] Byte[8] Byte[9] Byte[10] Byte[11]
0x06 0x01 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00
Byte[n] Byte[0] Byte[1] Byte[2]..[11]
Byte description Source Mode Data
Command 0x06 0x01 0x00
Command description Computer Single Axis Mode Dummy
7.4. Commands for Mode Selection
Following shows the command of mode selection:
