Page 46
DWL-5x000XY DATA SHEET
Byte [n] Command Descriptions
Byte [0] 0x06 From Computer
Byte [1] 0x01 To Sensor
Byte [2] 0x08 Location Mode
Byte [3]
0x00
Country Index**
(Please refer to Appendix 2 Country and City index)
Byte [4]
0x00
City Index**
(Please refer to Appendix 2 Country and City index)
Byte [5]~[6] 0x00 Not Applicable
Byte [7] 0x5A Location Write Command
Byte [8]~[11] 0x00 Not Applicable
*Only require for for sensor module model DWL-5500XY & DWL-5800XY
**User is required to select the country and city (or its nearest city/location) where device is operating
***User can refer to APPENDIX 2: Country and City Index for the list of the
Data received from tilt sensor module:
>> (From sensor) : 0x61 0x18, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00
7. Serial Communication Protocol for Control Box
7.1. Serial Port Settings
Following are the serial port settings to enable the serial communication:
Baud Rate 115200
Parity None
Data Bits 8
Stop Bits 1 Stop Bit
Handshake None
7.2. Buffer Frame Format
Buffer Format : Hexadecimal
Buffer Length : 12 bytes
The data to be transmitted out to tilt sensor module is as follow:
Source Destination Data
1 Byte 1 Byte 10 Byte
Source (1 byte) : Sender command
Destination (1 byte) : Receiver command
