DWL-5x000XY DATA SHEET
Command Descriptions
0x01 Single Axis Mode
0x02 Dual Axis Mode
0x03 Vibro Mode
0x0B Calibration Mode
0x07 Alternate Zero in SIngle Axis Mode
0x0A Alternate Zero in Dual Axis Mode
0x20 Relay Mode
0x55 Connection Status Mode
The detailed information of each command is explained in Section 7.4.1 to 7.4.7 Please
note that all the angle values and CRC16 values are for illustration purposes only.
7.4.1. Single Axis Mode
To set the tilt sensor module into Single Axis Mode:
<< (To control box) : 0x06, 0x01, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00
Byte [n] Command Descriptions
Byte [0] 0x06 From Computer
Byte [1] 0x01 Single Axis Mode
Byte [2] 0x01
Not Applicable
Byte [3]~[11] 0x00
Data received from control box:
>> (From control box) : 0x71, 0x11, 0x01, 0x12, 0xA8, 0x80, 0x01, 0x13, 0x88, 0xAA, 0x16, 0x46
