- 22 -
3.9 WIFI Connec�on
3.8 Earth Connec�on(mandatory)
Ground cable shall be connected to ground plate on grid side, this prevents electric shock if the
original protec�ve conductor fails.
For the configura�on of Wi-Fi Plug, please refer to illustra�ons of the Wi-Fi Plug. The Wi-Fi Plug
is not a standard configura�on, it's op�onal.
Earth connec�on (Copper wires)
Warning:
Inverter has built-in leakage current detec�on circuit, The type A RCD can be
connected to the inverter for protec�on according to the local laws and regula�ons.
If an external leakage current protec�on device is connected, its opera�ng current
must be equal to 300 mA or higher, otherwise inverter may not work properly.
Pass the Meter communica�on cable
through the magne�c ring and wrap
it around the magne�c ring four �mes.
9
9
Model Wire Size Cable(mm )
2
Torque value(max)
7/7.6/8/10kW 6AWG 10 1.2Nm
Model Wire Size Cable(mm )
2
Torque value(max)
7/7.6/8/10kW 6AWG 10 1.2Nm
Earth connec�on (Copper wires) (Bypass)
