- 33 -
①②③ DC Breaker for battery
SUN-10K-SG-US: 300A DC breaker
SUN-12K-SG-US: 300A DC breaker
⑤⑦⑨ AC Breaker for grid port
SUN-10K-SG-US: 100A AC breaker
SUN-12K-SG-US: 100A AC breaker
④⑥⑧ AC Breaker for backup load port
SUN-10K-SG-US: 100A AC breaker
SUN-12K-SG-US: 100A AC breaker
L wireCAN N wire PE wire
Inverter
Inverter
No.3
(slave)
Inverter
No.2
(slave)
Inverter
No.1
(master)
Parallel
Master
Slave
Modbus SN
01
A Phase
B Phase
C Phase
Advanced Function
Paral.
Set3
Parallel
Master
Slave
Modbus SN
02
A Phase
B Phase
C Phase
Advanced Function
Paral.
Set3
Parallel
Master
Slave
Modbus SN
03
A Phase
B Phase
C Phase
Advanced Function
Paral.
Set3
Master inverter Slave Inverter Slave Inverter
Parallel A Parallel B
Battery pack
① DC
Breaker
② DC
Breaker
③ DC
Breaker
Grid
Backup Load
L1
L2
N
PE
L2L1
CT1
CT2
NPE
Ground
Home Load
⑤
⑦
⑧
⑩ AC
Breaker
CT
Arrow pointing
to
inverter
The primary side of the CT
needs to be clamped on the
Grid live line.
④
⑥
⑨
SUN-(10-12)K-SG02LP2-US-AM3
