- 23 -
3.12 Split phase (120/240Vac) parallel connec�on diagram
Inverter
Inverter
No.3
(slave)
Inverter
No.2
(slave)
Inverter
No.1
(master)
Parallel
Master
Slave
Modbus SN
01
A Phase
B Phase
C Phase
Advanced Function
Paral.
Set3
Parallel
Master
Slave
Modbus SN
02
A Phase
B Phase
C Phase
Advanced Function
Paral.
Set3
Parallel
Master
Slave
Modbus SN
03
A Phase
B Phase
C Phase
Advanced Function
Paral.
Set3
Master inverter Slave Inverter Slave Inverter
Parallel A Parallel B
Battery pack
① DC
Breaker
② DC
Breaker
③ DC
Breaker
Grid
Backup Load
L1
L2
N
PE
L2L1
CT1
CT2
NPE
Ground
Home Load
⑤
⑦
⑧
⑩ AC
Breaker
CT
Arrow pointing
to
inverter
The primary side of the CT
needs to be clamped on the
Grid live line.
④
⑥
⑨
①②③ DC Breaker for battery
⑤⑦⑨ AC Breaker for grid port
④⑥⑧ AC Breaker for
backup load port
⑩ AC Breaker
Depends on Home Load
SUN 5K-SG: 40A AC breaker
SUN 6K-SG: 40A AC breaker
SUN 7.6K-SG: 63A AC breaker
SUN 5K-SG: 150A DC breaker
SUN 6K-SG: 200A DC breaker
SUN 7.6K-SG: 200A DC breaker
SUN 5K-SG: 40A AC breaker
SUN 6K-SG: 40A AC breaker
SUN 7.6K-SG: 40A AC breaker
SUN 8K-SG: 63A AC breaker
SUN 8K-SG: 63A AC breaker
SUN 8K-SG: 250A DC breaker
(Region:US)
L wireCAN N wire PE wire
Note: For the parallel system, please choose the "Zero export to CT " mode.
