Sensor Clamp
x 3
- 07 -
3.2 Mounting instructions
Installation Precaution
DC+/DC- Plug connectors
including metal terminal
xN
Battery Plug connectors
accessories x4
T-type wrench
x1
Stainless steel mounting
screws M4*12 x9
Solar Photovoltaic
Connector Special
Spanner x1
7,*8,*9
Magnetic ring for AC
wires x3
(80×50×25 mm)
4,5,6
Magnetic ring for CT x3
(31×29×19 mm)
Magnetic ring for
commuication cable of
BMS and Meterx3
(23×33×15 mm)
1,2,3
Matching Resistor x1
*8 &*9 are placed on the top of the
EPE material upper cover
1,2,3 : 23×33×15 mm
4,5,6 : 31×29×19mm
7,8,9 :80×50×25 mm
Packing box of magnetic ring
1 2
3
4
5
6
7
