Pic 7.18 Zero-export function via energy meter turn on
PARAMETR Meter
Meter Power:
Load Power:
Day
ImpEp : 9.51kWh 2.24MWh
ExpEp : 0.00kWh 574.75KWh
LoadEp : 13.71kWh 1.67MWh
428W
SN:1
1.043kW
Total
Pic 7.17 Zero-export function via meter setting interface
MENU 》Setup》Run Param
OK Cancel
ActiveP 31%
ReactP 0.0%
QMode QU
PF 1.000
Fun_ISO ON
Fun_RCD ON
Island OFF
Meter ON
Limiter OFF
Feed_In 0%
MPPT Num 4
SelfCheck 20S
5. Meter power 428W shows positive means grid is supplying the load, and no power fed into
grid. if meter power shows negative, it means PV energy is being sold to grid or energy meter
wiring conncetion has problem.
6. After properly connection is done, wait for inverter starting. If the power of the PV array
meets the current power consumption, the inverter will keep a certain output to counteract
the power of the grid without backflow .
2. Operate the button [up down], move setting cursor to energy meter and press the button
[enter]. At this time you can turn on the energy meter by choosing [up down] button, please
press [enter] button to confirm when setting done.
3. Move the cursor to [OK], press [enter] to save the settings and exit the running
parameters page, otherwise the settings are invalid.
4. If set up successfully, you can return to the menu interface, and display the LCD to [home
page] by press the [up down] button. If it displays [meter power XXW], the zero-export
function setting is completed. Shown as picture 7.18.
1. Press Enter button on the LCD panel in the main interface into the menu options, select
[parameter setting] to enter setup submenu, and then select [run param], at this time please
input the default password 1234 through pressing the button [up down, enter], enter the
operation parameter setting interface, shown as picture 7.17.
- 28 -
