7. Zero-export function via energy meter
There're several usable models of smart meters for this series inverter. First model is Eastron
SDM630-Modbus V2 which is able to measure the Max. 100A current directly, More details
please refer to Pic7.1 & 7.4. For the Eastron SDM630 MCT 40mA, it needs external CT with a
40mA secondary output current. More details about the Eastron SDM630 MCT, please refer
toPic 7.5 & 7.8. Also, the CHINT meter DTSU666 5(80) A is also supported, it can measure the
Max. 80A current directly. More usable models of DTSU666 series , please refer to Pic 7.9 - 7.16.
Suggest purchasing smart meters from authorized distributors of Deye or directly from Deye.
When you are reading this, we believe that you have completed the connection according to
the requirements of chapter 5, if you have been running your inverter at this time, and you
want to use the zero-export function, please turn off AC and DC switch of the inverter, and wait
for 5 minutes until the inverter completely discharged.
For system wiring diagram, the red line refers to L line (L1, L2, L3), the black line refers to the
neutral line (N). Connecting energy meter RS485 cable to inverter's RS485 port. It's recommend-
ed to install an AC switch between the inverter and the utility grid, the specs of the AC switch
are determined by the power of load.
If there is no integrated DC switch inside the inverter you purchased, we commend you to
connect the DC switch. The voltage and current of the switch depend on the PV array you
access.
- 19 -
Warning:
The PID functionality is automatic.When the DC bus voltage is below 50VDC, the PID module
will create 450VDC between the PV and ground.No control and equipment are required.
Warning:
If you need to maintain the inverter, Please turn off the AC switch first,then turn off the DC switch,
and wait 5 minutes before you do other operations.
Add a PCB board which uses AC power to supply the LCD screen and data logger , and then the inverter
can upload consumption power data to the cloud platform during night. This feature is optional.
6.4 LCD night power supply(optional)
