Grid Setting/F(W)

F(W)

Start freq F

Over frequency

50.20Hz

Start delay F

0.00s

Stop freq F 51.5Hz

Droop F 40%PE/Hz

Stop delay F

0.00s

Start freq F

Under frequency

49.80Hz

Start delay F

Stop freq F 49.80Hz

Droop F 40%PE/Hz

Stop delay F

0.00s

Grid

Set4

Grid Setting/LVRT

L/HVRT

HV3

HV3_T

30.24s

HV2

HV2_T

0.04s

HV1

HV1_T

22.11s

LV1

LV1_T

22.02s

LV2

LV2_T

0.04s

Grid

Set7

Reserved: This function is reserved.It is not

recommended.

Grid Setting/V(W) V(Q)

V(W) V(Q)

108.0%

110.0%

112.0%

114.0%

100%

80%

60%

40%

Lock-in/Pn Lock-out/Pn

94.0%

97.0%

105.0%

108.0%

44%

-44%

Grid

Set5

20%

Grid Setting/P(Q) P(F)

P(Q) P(PF)

22%

21%

25%

PF2P2

PF3

PF4

62%

PF1

-0.000

0.000

0.264

Grid

Set6

Lock-in/Pn Lock-out/Pn

50%

F(W): It's used to adjust the output active power of inverter

according to the grid frequency.

Droop F: percentage of nominal power per Hz

For example, "Start freq F=50.2Hz, Stop freq F=51.5,

Droop F=40%PE/Hz" when the grid frequency reaches

51.2Hz, the inverter will decrease its active power at

Droop F of 40%. And then when grid system frequency

is less than 50.1Hz, the inverter will stop decreasing

output power.

For the detailed setup values, please follow the local

grid code.

V(W): It is used to adjust the inverter's active power

according to the set grid voltage.

V(Q): It is used to adjust the inverter's reactive power

according to the set grid voltage.

These two functions are used to adjust inverter's output

power (active power and reactive power) when grid

voltage changes.

Lock-in/Pn 5%: When the inverter active power is less

than 5% rated power, the V(Q) mode will not take eﬀect.

Lock-out/Pn 20%: If the inverter active power is

increasing from 5% to 20% rated power, the V(Q) mode

will take eﬀect again.

For example: V2=110%, P2=80%. When the grid voltage reaches 110% of the rated grid voltage,

inverter will reduce its active power output to 80% of the rated power.

For example: V1=94%, Q1=44%. When the grid voltage reaches 94% of the rated grid voltage,

inverter will output reactive power that accounts for 44% of the rated power.

For the detailed setup values, please follow the local grid code.

P(Q): It is used to adjust the output reactive power of

inverter according to the set active power.

P(PF): It is used to adjust the PF of inverter according

to the set active power.

For the detailed setup values, please follow the local

grid code.

Lock-in/Pn 50%: When the output active power of

inverter is less than 50% of inverter's rated power, it

won't enter the P(PF) mode.

Lock-out/Pn 50%:When the output active power of

inverter is higher than 50% of inverter's rated power,it

will enter the P(PF) mode.

Note : only when the grid voltage is equal to or higher

than 1.05 times of the rated grid voltage, then the P(PF)

mode will take eﬀect.
