Je bekijkt pagina 17 van 61
- 15 -
GRID
LOAD
E-BAR
E-BAR
GEN
N
L1
L2
L3
PE
Thread the end of wires through the
magne�c ring 7 and connect these wires to
the terminals of LOAD port corresponding to
the indica�on of polarity.
LOAD
GEN
GRID
Thread the end of wires through the
magne�c ring 8 and connect these wires to
the terminals of GEN port corresponding to
the indica�on of polarity.
7
8
Thread the end of wires through the
magne�c ring 9 and connect these wires to
the terminals of GRID port corresponding to
the indica�on of polarity.
9
7
8,9
