3.6.1 PV Module Selec�on:
3.6.2 PV Module Wire Connec�on:
When selec�ng proper PV modules, please be sure to consider below parameters:
1) Open circuit Voltage (Voc) of PV modules not exceeds max. PV array open circuit voltage of
inverter.
2) Open circuit Voltage (Voc) of PV modules should be higher than min. start voltage.
3) The PV modules used to connected to this inverter shall be Class A ra�ng cer�fied according
to lEC 61730.
- 18 -
1. Switch the Grid Supply Main Switch(AC)OFF.
2. Switch the DC lsolator OFF.
3. Assemble PV input connector to the inverter.
Chart 3-5
PV Input Voltage
Inverter Model
PV Array MPPT Voltage Range
No. of MPP Trackers
No. of Strings per MPP Tracker
550V (160V-800V)
160V-650V
2
2+2
SUN-14K-
SG05LP3-
AU-SM2
SUN-15K-
SG05LP3-
AU-SM2
SUN-16K-
SG05LP3-
AU-SM2
SUN-18K-
SG05LP3-
AU-SM2
SUN-20K-
SG05LP3-
AU-SM2
Safety Hint:
When using PV modules, please ensure the PV+ & PV- of solar panel is not
connected to the system ground bar.
Safety Hint:
Before connec�ng inverter, please make sure the PV array open circuit voltage is
within the 800V of the inverter.
Note:
This inverter complies with IEC 62109-2 clause 13.9 for earth fault alarm
monitoring. If an Earth Fault Alarm occurs,the inverter will not connect to the
grid and will report an error F04 on its LCD.At the same �me, the buzzer will
sound. For the machine installed with Wi-Fi/GPRS, the alarm informa on can be
seen on the corresponding monitoring website, and can also be received by the
APP on the mobile phone.
Safety Hint:
Before connec�on, please make sure the polarity of the output voltage of PV
array matches the “DC+” and “DC-” symbols.
