- 14 -
3.5 Grid connec�on and backup load connec�on
Please follow below steps to implement AC input/output connec�on:
· Before connec�ng to the grid, a separate AC breaker must be installed between the inverter
and the grid, and also between the backup load and the inverter.This will ensure the inverter
can be securely disconnected during maintenance and fully protected from over current. For
the 5/6/7.6/8/10/12kW model, the recommended AC breaker for backup load 5/6kW is 40A,
7.6/8kW is 63A, 10/12kW is 100A. For the 5/6/7.6/8/10/12kW model, the recommended AC
breaker for grid 5/6KW is 40A, 7.6/8KW is 63A, 10/12kW is 100A. In final installa�on, breaker
cer�fied according to AS60947.3 shall be installed with the equipment.
· There are three terminal blocks with "Grid" "Load"and "GEN" markings. Please do not misconnect
input and output connectors.
1. Before making Grid, load and Gen port connec�on, be sure to turn off AC breaker or
disconnector first.
2. Remove insula�on sleeve 10mm length, unscrew the bolts. For GRID port, just insert the wires
into the terminals according to polari�es indicated on the terminal block. For GEN and Load
ports, thread the wires through the magne�c ring firstly, then insert these wires into the
terminals according to polari�es indicated on the terminal block. Tighten the terminal screws
and make sure the wires are completely and safely connected.
Grid connec�on and backup load connec�on (Copper wires)
All wiring must be performed by a qualified personnel.It is very important for
system safety and efficient opera�on to use appropriate cable for AC input
connec�on. To reduce risk of injury, please use the proper recommended cable
as below.
Chart 3-3 Recommended Size for AC wires
Model
5/6kW
Wire Size
8AWG
Cable(mm )
2
6.0
Torque value(max)
1.2Nm
7.6/8/10/12kW 6AWG 10 1.2Nm
Model
5/6kW
Wire Size
8AWG
Cable(mm )
2
6.0
Torque value(max)
1.2Nm
7.6/8/10/12kW 6AWG 10 1.2Nm
Grid connec�on and backup load connec�on (Copper wires) (bypass)
