GRID
LOAD
N-BAR
E-BAR
GEN
GRID
GEN
LOAD
E-BAR
L1
L2
PE
PE
PE
N-BAR
N
N
N
Thread the end of wires through the
magne�c ring 4 and connect these wires to
the terminals of LOAD port corresponding to
the indica�on of polarity.
Thread the end of wires through the
magne�c ring 3 and connect these wires to
the terminals of GEN port corresponding to
the indica�on of polarity.
4
3
Thread the end of wires through the
magne�c ring 5 and connect these wires to
the terminals of GRID port corresponding to
the indica�on of polarity.
5
GEN LOAD GRID
3 4 5
- 14 -
