Panel Description
3
1
Turns the power on or o (p. 13).
With the factory settings VIVO SX7’s power will
automatically be switched o 120 minutes after you
stop playing or operating the VIVO SX7.
If VIVO SX7’s power has been turned o automatically,
you can use the [POWER] switch to turn the VIVO SX7
back on. If you don’t want the power to turn o
automatically, set the “AUTO OFF” parameter to “OFF”
(p. 43).
NOTE
To avoid malfunctions, never disconnect the AC/DC adaptor while
the instrument is turned on.
2
USB Memory Port
• You can connect an commercially available USB
Memory to save or load Memories, Sound Set and other
data (p. 12).
• Using an AgB-type cable, you can connect keyboards
from any brand directly to this port to exchange MIDI data
without a computer and without using two MIDI cables (p.
"Main Connections" (p. 17).
NOTE
* Carefully insert the USB Memory or USB cables making sure that
the connector on the device is appropriate and that it is connected
in the proper direction.
3
Arrow buttons
These buttons are used to navigate around the
various menus and adjust values.
4
Function buttons
These buttons are used to select one of three
functions/options shows at the bottom of the display.
Press the rst and the last Function button to listen
the demo song.
5
This display shows information related to your
operation.
The last row of the display shows the functions that
you can recall pressing one of three the button below
the display.
6
MENU/EXIT
This button allows you to open and close the menu
page where you can view and select all available
functions.
7
MEMORY/WRITE button
This button allows you to shows the list of memories
and then recall one of them. (See p. 32).
Pressing and holding this button to write a memory
(See p. 32).
8
SOUND
You can change the sound of the currently selected
part, and it displays the tone list. See p. "Selecting the
Tones" (p. 19).
9
PHONES output
This is where you can connect a pair of optional
headphones.
10
DATA ENTRY
Use this to edit values.
11
VOLUME
Use this knob to set VIVO SX7’s overall volume.
12
Rack-mount bracket
Use these when installing the VIVO SX7 in a 19-inch
rack.
For details on how to install the VIVO SX7 in a rack,
refer to the owner’s manual included with the rack
you’re using.
4
5
6789
1011
3
2
1
12
