13
Ground Terminal
NOTE
Carefully insert the USB Memory making sure that the connector
on the device is appropriate and that it is connected in the
proper direction.
Safely Remove the USB Memory
NOTE
You should always safely eject the USB Memory before
physically unplugging it from USB socket. Before to unplug the
USB Memory use the "USB REMOVE" function.
1. Press the [MENU/EXIT] button.
2. Use the [] [] buttons to scroll the list and select the
"USB REMOVE" function.
3. Press the [] buttons to access the function.
The display shows:
4. Press the "YES" Function button to safely remove the USB
Memory.
Now you can unplug the USB Memory safely.
Ground Terminal
Depending on the circumstances of a particular setup, you could
feel a tingling sensation at the point where touch this device.
You can eliminate this sensation connecting the ground terminal
with an external ground.
1. Use the screw-type ground terminal to connect to ground
or to connect to the chassis of the mixer, preamp, or other
device in your system.
Turning the Power On/O
Once everything is properly connected, be sure to follow the
procedure below to turn on their power.
1. Rotate the [VOLUME] knob counterclockwise to minimize
the volume.
NOTE
Before turning the VIVO SX7 on/o, always be sure to turn the
volume down. Even with the volume turned down, you might
hear some sound when switching the VIVO SX7 on/o.
However, this is normal and does not indicate a malfunction.
2. Press the VIVO SX7’s [ " ] button located on the right
panel to switch it on.
The power will turn on, a progress bar appear in the VIVO SX7’s
display.
After a brief interval, the main page will appear. and VIVO SX7 will
be ready to produce sound.
3. Use the [VOLUME] knob to adjust the volume.
NOTE
This unit is equipped with a protection circuit. A brief interval
(a few seconds) after power up is required before the unit will
operate normally.
