18
Before You Start to Play
Closing the Music Rest
1.
Pull up the sheet music holder (1) as in the illustration
below.
2. Pull up the front part of the lid (2) as in the illustration
below.
1
2
Closing the Lid
WARNING
• Allow the lid to close automatically. Do not force the lid.
• Be careful to avoid catching your ngers when closing the lid.
Adult supervision is recommended whenever small children
use the unit.
1. Before closing the lid, close the sheet music holder. See
"Closing the Music Rest" as described above.
2. Hold the lid with both hands and slowly accompany it to
close automatically.
Allow the lid to close automatically. Do not force the lid.
Connecting the VIVO H6 to Your
Computer
If you use a USB cable (commercially available) to connect the VIVO H6 to
your computer, you can record and play audio and/or MIDI data with your
MIDI software (DAW software).
NOTE
VIVO H6 does not support GM/GS standard.
What do you need to connect the VIVO H6 to your
computer?
• USB cable (type A–male - type B–male: commercially available)
1. Use a standard USB cable (AgB-type connectors,
commercially available) to connect the VIVO H6 to your
computer as shown below.
USB MIDI + AUDIO Streaming
NOTE
• Switch on the VIVO H6 before you start up the DAW software
on your computer.
• Before connecting any other equipment, move the [VOLUME]
knob counterclockwise to minimize the volume.
Now, the same sound coming out of the VIVO H6 can be recorded
into your computer and the sound from your computer can be
played from the audio system of the VIVO H6.
Connecting the VIVO H6 to a USB MIDI
Keyboard (USB host function)
Using the following connection, your piano becomes a master (host). You
can connect other keyboards or modules from any brand directly to the
DEXIBELL USB “Memory” port and exchange MIDI data without a computer
and without using two MIDI cables.
The connection consists of the following main components:
• Your DEXIBELL piano.
• One slave MIDI USB Devices as a keyboard.
• A physical bus is represented by a USB cable that links the devices
with the host .
VIVO H6 - Master (host)
USB cable AgB-type
Slaves
USB "Computer" port
USB "Memory" port
