42
Advanced Functions
18
The CLASSICO L3’s [FUNCIONT/EXIT] button provides access to the
available parameters and functions.
General procedure
1. Press and hold the [FUNCTION/EXIT] button.
PIANO
HARPSICHORD
TUNING TEMPERAMENT TRANSPOSE
The [FUNCTION/EXIT] button ashes to indicate that we are in
function mode. All other indicators go dark.
2. Press the lower part of the tilt tab associated with the
function you want to recall.
In the example above we selected the Expression Pedal Settings.
3. According to the called function, press the [1,2,3,4]
piston that corresponds to the parameter you want to set.
PHONESAUDIO IN
The following parameters and functions are available:
Functions
Import Memory Function ....................................42
Export Memory Function ....................................42
Expression Pedal Settings ....................................43
MANUAL II/ORCHESTRA ......................................43
ALL ...........................................................43
ORCHESTRA (
MANUAL II) ........................................43
ORCHESTRA (MANUAL I and PEDAL) ............................43
Damper Pedal Settings ......................................43
PIANO ........................................................43
PIANO, ORCHESTRA (
MANUAL I) .................................43
PIANO, ORCHESTRA (PEDAL) ...................................43
PIANO, ORCHESTRA (PEDAL and MANUAL I) .......................43
Speakers Settings ...........................................43
AUTO .........................................................43
ON ............................................................43
OFF ...........................................................43
AUTO OFF Settings ..........................................43
60 minutes ....................................................43
120 minutes ..................................................43
240 minutes ..................................................43
LOCAL ON/OFF Settings ......................................43
OFF ...........................................................43
ON ............................................................44
Factory Reset ................................................44
MIDI PedalBoard ............................................44
Enable ........................................................44
Disable ........................................................44
Importing Organ Sound Set (User 1/2) ........................44
Deleting Organ Sound Set (User 1/2) ..........................44
USB Remove .................................................44
Keyboard Touch Response ....................................45
LIGHT PLUS ...................................................45
LIGHT .........................................................45
NORMAL ......................................................45
HEAVY ........................................................45
BLUETOOTH (make it visible) .................................45
CRESCENDO PEDAL ..........................................45
Crescendo ....................................................45
Damper .......................................................45
CRESCENDO SETTING MODE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
IMPORT CRESCENDO SETTING ................................45
EXPORT CRESCENDO SETTING ................................45
Import Memory Function
[FUNCTION/EXIT] button 1
This function allow you to import a Registrations Set from an USB Memory.
For details see "Importing a Registration Set from an USB Memory" (p.
34).
Export Memory Function
[FUNCTION/EXIT] button 2
This function allow you to export a Registration Set into an USB Memory.
For details see "Exporting a Registration Set to an USB Memory" (p. 33).
