fast, secure connection between the hose
and power tool. The connector connects directly
to D
EWALT compatible tools or through the use
of an adapter (available from local D
EWALT supplier).
If you need to Install the adapters, refer to
Fig. E.
NOTE: If using an adapter ensure it is rmly
attached to the tool outlet before following the steps
below.
IMPORTANT SAFEGUARDS
The symbol on the product or packaging indicates that
the product must not be treated as domestic refuse.
Instead, it should be handed in to a collection point for
the recycling of electrical and electronic components.
By ensuring the product is treated in the right way, this
will help to prevent the negative impact on environment
and health that may result from the product being thrown
away as general waste. For further information about
recycling, you should contact the local authorities, refuse
collection service or the sales outlet where you bought
the goods.
PROTECTING THE ENVIRONMENT
Separate collection. Products and batteries
marked with this symbol must not be
disposed of with normal household waste.
Products and batteries contain materials that can be
recovered or recycled reducing the demand for raw
materials. Please recycle electrical products and
batteries according to local provisions. Further
information is available at www.2helpU.com
1
Top handle/cord wrap
2
Power cord
3
On/off switch
4
Vacuum head
5
Lid latches
6
Dust tank
7
9
Hose
8
Casters
9
Clean Connect lter
TM
10
Vacuum port
11
Hose strap
12
Disposable dust bag
13
Drain port
14
Wheel
15
Accessory bag with holder
DESCRIPTION (Fig. A)
ASSEMBLY AND ADJUSTMENTS (Fig. A–C)
WARNING : Never modify the power appliance or
any part of it. Damage or personal injury could result.
WARNING: To reduce the risk of injury, turn
appliance off and disconnect appliance from
power source before installing and removing
accessories, before adjusting or changing
set-ups or when making repairs. An accidental
start-up can cause injury.
WARNING: The lter must always be in
place while vacuuming, except as described
under WET PICK UP APPLICATIONS under
OPERATION. When vacuuming ne dust, you
may also need to use an disposable dust bag to
make emptying the dust tank easier.
3
4
5
7
10
10
7
12
OPERATION
INSTRUCTIONS FOR USE (Fig. A, D, E)
WARNING: Always observe the safety instructions
and applicable regulations.
1. Plug the power cord into an appropriate outlet.
2. Turn the on/off switch to the ON position ( I ).
3. The D
EWALT construction dust extractor is tted
with the D
EWALT connection system. It allows a
1. Install the disposable dust bag , as shown
in Fig. B.
NOTE: Be careful not to tear the bag. Place bag
securely onto vacuum port to provide a tight
seal for maximum dust collection performance.
2. Place the vacuum head onto the dust tank and
secure it by closing the lid latches .
3. Insert the end of hose into clip-in hose vacuum
port and tighten the end of hose to the tank.
4
5
10
12
12
12
REMOVE/CHANGE USED DISPOSABLE
DUST BAG (Fig. A)
WARNING: Appropriate personal protective
equipment like dust mask and gloves should be used
while handling used dust bags.
1. Turn off vacuum and unplug cord from outlet.
2. Unlatch lid latches and remove vacuum head .
3. Pull the disposable dust bag carefully from vacuum
port .
4. Seal the disposable dust bag opening tightly when
removing it from the machine.
5. Dispose the disposable dust bag in appropriate
container according to statutory provisions.
English
17
Attach 2 accessory bag holder brackets to tank with
4 self-tapping screws provided.
ACCESSORY BAG HOLDER
ASSEMBLY (Fig. A, F)
Insert the main handle into side accessory bag holder
brackets , until hearing the “click” sound, and the
installation is completed.
MAIN HANDLE ASSEMBLY (Fig. A, F)
OPERATING INSTRUCTIONS
CASTER INSTALLATION (Fig. A, F)
1. Invert dust tank , take the caster to align the tank
bottom sinking place. Secure with screws provided.
2. Slide the rear wheel on axle, and install the
pin & washer. And insert the wheel cap into the rear
wheel until wheel cap snap into place.
3. Return dust tank assembly upright.
6
