English
5
5
4
Fig. G
10
11
Attaching a Dust Extractor to the Dust
Extraction Assembly (Fig. H–J)
1. Insert the dust hose
8
into the dust extraction
connection port
7
and a dust extractor (Fig. H).
nOTE: The dust extraction system is compatible with
or without a dust extractor. The tool can be used
with the plug
17
inserted in the dust extraction
connection port
7
(Fig. I). If you are using the plug, it
is recommended you remove the dust from the bellow
after drilling eachhole.
8
7
Fig. H
17
Fig. I
AirLock Compatible (Fig. A, H–J)
Your D
e
WALT dust extractor is compatible with the D
e
WALT
AirLock connection system. The AirLock allows for a fast,
secure connection between the dust hose
8
and power
tool. The AirLock connector
20
(Fig. J) connects directly to
D
e
WALT compatible tools or through the use of an AirLock
adapter
21
(available from your local D
e
WALTsupplier).
nOTE: If using an AirLock adapter
21
, ensure it is firmly
attached to the tool outlet before following the stepsbelow.
1. Ensure the collar on the AirLock connector is in the
unlock position. (Refer to FigureJ.) Align notches
23
on
collar and AirLock connector as shown for unlock and
lockpositions.
2. Push the AirLock connector onto the dust extraction
system hose
8
.
3. Rotate the collar to the lockedposition.
nOTE: The ball bearings inside collar lock into the slot
and secure the connection. The dust extraction system is
now securely connected to the dustextractor.
20 21
2323
Fig. J
Removing the Dust Extraction System
from the Tool (Fig. A, I)
1. Remove the dust hose
8
or the dust port plug
17
from
the dust extraction connection port
7
.
2. Remove the bit from the toolholder.
3. Turn side handle
1
to loosen and slide from the nose
of thetool.
4. If a ring adapter was used, open and remove the adapter
from the nose ofthetool.
OPERATION
Instructions for Use
WARNING: Always observe the safety instructions
and applicableregulations.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect tool from
power source before making any adjustments or
removing/installing attachments or accessories.
Be sure the trigger switch is in the OFF position. An
accidental start-up can causeinjury.
