ENGLISH
6
Register Online
Thank you for your purchase. Register your product nowfor:
• WARRANTY SERVICE: Registering your product will help
you obtain more efficient warranty service in case there is a
problem with yourproduct.
• CONFIRMATION OF OWNERSHIP: In case of an
insurance loss, such as fire, flood or theft, your registration of
ownership will serve as your proof ofpurchase.
• FOR YOUR SAFETY: Registering your product will allow
us to contact you in the unlikely event a safety notification is
required under the Federal Consumer SafetyAct.
Register online at www.dewalt.com/account-login.
Repairs
The charger and batteries are notserviceable. There are no
serviceable parts inside the charger or batterypack.
The vibrator contains no user serviceable parts.
WARNING: To assure product SAFETY and RELIABILITY,
repairs, maintenance and adjustment (including brush
inspection and replacement, when applicable) should be
performed by a factory service center or an authorized service
center. Always use identical replacementparts.
Accessories
WARNING: Since accessories, other than those offered by
DeWALT, have not been tested with this product, use of such
accessories with this product could be hazardous. To reduce
the risk of injury, only
DeWALT‑recommended accessories
should be used with thisproduct.
Recommended accessories for use with your product are
available at extra cost from your local dealer or authorized
service center. If you need assistance in locating any
accessory, please contact
DeWALT. Call 1-800-4-DeWALT
(1-800-433-9258) or visit our website: www.dewalt.com.
Shaft Lubrication
Do not disassemble vibrator head. The vibrator head is sealed
at the factory and contains a special high‑performance
lubricant. Breaking the seal and adding incorrect lubricant
will significantly decrease the performance and life of the
tool. If vibrator head is damaged or needs lubricant, take the
tool to a
DeWALT authorized servicecenter.
MAINTENANCE
WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/installing
attachments or accessories. An accidental start‑up can
causeinjury.
Your DeWALT power tool has been designed to operate
over a long period of time with minimum maintenance.
Continuous satisfactory operation depends upon proper
tool care and regularcleaning.
After Use
WARNING: Do not let the machine run outside of the
freshly mixed (green) concrete.
WARNING: Risk of burning from hot surface.
WARNING: Damage to the machine from increased wear.
If Vibrator Head Becomes Too Hot
1. Slowly pull the vibrator head
1
out of the freshly mixed
(green) concrete and hold it in the air.
2. Turn the
DeWALT POWERSHIFT™
control dial
to
the
offposition.
3. Wait until the vibrator head
1
comes to a complete stop.
4. Disconnect the shaft
2
from the DeWALT POWERSHIFT™.
Rotate the quick change quick change collar
4
clockwise
and pull the quick change plug
3
from the quick change
collar
4
and DeWALT POWERSHIFT™ unit.
5. Allow the vibrator head
1
to cool down before attempting
to use again.
Cleaning
WARNING: Blo
w dirt and dust out of all air vents with
clean, dry air at least once a week. To minimize the risk of eye
injury, always wear ANSI Z87.1 approved eye protection when
perform
ing thisprocedure.
WARNING: Never use solvents or other harsh chemicals
for cleaning the non‑metallic parts of the tool. These chemicals
may weaken the plastic materials used in these parts. Use a cloth
dampened only with water and mild soap. Never let any liquid get
inside the tool; never immerse any part of the tool into aliquid.
WARNING:
DO NOT clean with a high pressure cleaner.
Signs that the concrete has been
sufficiently compacted:
• Concrete no longer settles.
• Little to no air bubbles are rising any longer.
To Operate
1. Turn vibrator on.
2. Using both hands, hold the shaft
2
.
3. Immerse the vibrator head into the freshly mixed (green)
concrete allowing the weight of the vibrator head to
fullypenetrate.
4. Guide the vibrator head through the freshly mixed
concrete, then slowly lift vibrator head out to avoid
retrapping air. Small up and down movements will close
any holes formed by the vibrator head.
5. Move the vibrator head to the next location andrepeat.
NOTE: Lift the head vertically from the mix at a rate of
about 3 seconds per foot of thickness of the concrete.
NOTE:
For best results, it is usually best to keep the
vibrator head vertical at all times and to avoid side‑to‑
sidemovement.
NOTE: Compact particularly intensely within formwork
corners as reinforcement density is the greatest there.
NOTE: If a small diameter vibrator head is used, it must be compacted
longer to achieve the same effect as with a largediameter.
IMPORTANT: Do not drag the head through the mix,
as this will form mortar channels (areas where there is
nostone). Once the head reaches the surface, remove it
quickly to avoid churning the concrete at the surface.
