14
EnGLIsh
Cut a piece of 38mm x 89mm timber
43
(about 61cmlong)
to keep blades from turning when removing the blade
assemblybolt
44
.
WARNING: Use gloves and proper eye protection. Turn the
mower on its side. Be careful of sharp edges ofblades.
1. Position the mower on its side, with two wheels flat on
theground.
2. Position the 38mm x 89mm timber
43
between the blade
assembly
48
and outer lip of deck as shown in Fig. X to
keep the blades fromturning.
3. Unscrew and remove the blade assembly bolt
44
counterclockwise with a 14 mm (9/16") wrench
45
(not
included) as shownin Fig.X, Y.
4. Remove the keyed spacer
46
and blade assembly
48
from
the blade shaft
50
.
5. Secure the blade assembly
48
in a vise
49
as shown inFig. Z.
6. Unscrew the four blade nuts
52
counterclockwise
with a 14 mm (9/16") wrench
45
(not included) as
showninFig.Z. First unscrew the two blade nuts
52
for
blade 2
53
and remove blade 2. Then unscrew the two
blade nuts
52
for blade 1
54
and pull blade 1from the
blade hub
55
.
nOTE: The mower blades
53
and
54
have keyed
mounting holes
56
permitting them to only be installed
onto the blade hub
55
in the correctorientation.
7. Examine all pieces for damage and replace ifnecessary.
8. Install sharpened or new blades onto the blade hub
55
as
shown in Fig.AA, BB.
9. Blade 1
54
is installed first, the bolt holes being aligned
with the outer blade studs
57
and keyed mounting
hole
56
on the blade hub
55
as shown in Fig. AA.
nOTE: Ensure the keyed mounting hole
56
engages the
key
58
on the blade hub
55
as shown in Fig.AA. The
key
58
should be proud of blade 1
54
.
10. Blade 2
53
is installed second, the bolt holes being aligned
with the inner blade studs
59
and keyed mounting
hole
56
on the blade hub
55
as shown inFig.BB.
nOTE: Ensure the keyed mounting hole
56
engages
the key
58
on the blade hub
55
and sits flush as shown
inFig.BB.
nOTE: If blade 2
53
is not flush with the key
58
on the
blade hub
55
, then the blades have been mounted in the
incorrect order and must bereversed.
11. Thread the four blade nuts
52
onto the bladestuds
57
and
59
as shown in Fig. AA, BB. Hand tighten the four
blade nuts
52
.
nOTE: When replacing sharpened or new blades on blade
hub
55
make sure the bottom of the blade as marked
Grass Side will be facing the ground when the mower is
returned to its normal uprightposition.
12. Secure the blade assembly
48
in a vise
49
. Tighten the four
blade nuts
52
clockwise with a 14 mm (9/16") wrench
45
(not included). Torque the four blade nuts
52
to 18-27 Nm
(13-20ft-lbs).
13. In this order, install the blade assembly
48
and keyed
spacer
46
onto the blade shaft
50
as shown in Fig. CC.
nOTE: Align the keys
47
on the keyed spacer
46
with the
key slots
51
on the bladeshaft
50
as shown in Fig.CC.
14. Install the blade assembly bolt
44
and handtighten.
15. Position the 38mm x 89mm timber
43
between the blade
assembly
48
and outer lip of deck as shown in Fig. DD to
keep the blades fromturning.
16. Fully tighten the blade assembly bolt
44
using a
14 mm (9/16")wrench
45
(not included). Torque the blade
assembly bolt
44
to 50-68 Nm (37-50 ft-lbs).
17. Return the mower to its normal uprightposition.
Blade Sharpening
KEEP BLADE SHARP FOR BEST MOWER PERFORMANCE. A DULL
BLADE DOES NOT CUT GRASSCLEANLY.
WARNING: Use gloves and proper eye protection while
removing, sharpening, and installing blades. Ensure that
safety key and battery pack(s) areremoved.
Sharpening the blades twice during a mowing season is usually
sufficient under normal circumstances. Sand causes the blade
to dull quickly. If your lawn has sandy soil, more frequent
sharpening may berequired. REPLacE BEnT OR DaMaGED
BLaDEsIMMEDIaTELY.
When Sharpening a Blade:
• Make sure blade remainsbalanced.
• Sharpen blades at the original cuttingangle.
• Sharpen cutting edges on both ends of blade, removing
equal amounts of material from bothends.
To Sharpen Blade in a Vise (Fig.EE)
1. Be sure the bail handle is released, the blades have stopped
and safety key and battery pack(s) are removed before
removing theblades.
2. Remove blades from mower. See instructions for Removing
and InstallingBlades.
3. Secure blade
53
or
54
in a vise
49
.
4. Wear proper eye protection and gloves and be careful not
to cutyourself.
5. Carefully file the cutting edges of the blade with a fine tooth
file
60
(not included) or sharpening stone (not included),
maintaining the angle of the original cuttingedge.
6. Check balance of blade. See instructions for BladeBalancing.
7. Replace blades on mower and tightensecurely.
Blade Balancing (Fig. FF)
Check balance of each blade
53
or
54
by placing the keyed
mounting hole
56
over a nail or round screwdriver
61
,
clamped horizontally in a vise
49
. If either end of a blade
rotates downward, file along the sharp edge of that dropping
end. Blade is properly balanced when neither enddrops.
Cleaning (Fig. A)
WARNING: Blow dirt and dust out of all air vents with
clean, dry air at least once a week. To minimize the risk
