45
EnGLISh
allows the guide bar
15
to recede and reduces the tension on
the chain so that it may beremoved.
5. Wearing protective gloves, grasp the saw chain and
guidebar and lift them away from the tool.
6. Wearing protective gloves, use a clean, soft bristle brush to
wipe away any saw dust or other debris that may have collected
on the guide bar
15
and around the saw chain
16
.
7. Install the chain, guide bar and sprocket cover
17
as
described in Installing the Guide Bar and Saw Chain,
Replacing the Saw Chainsections and adjust chain tension
properly before use as described in theAdjustingChain
Tensionsection.
Saw Chain and Guide Bar
After every few hours of use, remove the sprocket cover, guide
bar and chain and clean thoroughly using a soft bristle brush.
Ensure oiling hole on bar is clear of debris. When replacing dull
chains with sharp chains it is good practice to flip the guide bar
from bottom totop.
Optional Accessories
WARNING: Since accessories, other than those offered by
DeWALT, have not been tested with this product, use of such
accessories with this tool could be hazardous. To reduce the risk
of injury, only
DeWALT-recommended accessories should be used
with thisproduct.
Consult your dealer for further information on the
appropriateaccessories.
Motor Vent Screens (Fig. X, Y)
To get the best possible performance from your pole saw it is
important to keep the motor vent screens
53
clean.
1. Using a torx bit or flathead screwdriver, remove
the screws
54
and lift the vent screens away from the
motorhousing.
2. Rinse out the motor vent screens
53
with warm
soapywater.
3. Ensure the motor vent screens
53
are completely dry before
refitting into the motorhousing.
4. Install and tighten the screws
54
to secure the motor vent
screens
53
to the motor housing.
Cleaning
WARNING: Electrical shock and mechanical hazard. Remove
the battery beforecleaning.
WARNING: To ensure safe and efficient operation, always
keep the electrical appliance and the ventilation slotsclean.
WARNING: Never use solvents or other harsh chemicals for
cleaning the non-metallic parts of the tool. These chemicals may
weaken the materials used in these parts. Use a cloth dampened
only with water and mild soap. Never let any liquid get inside the
tool; never immerse any part of the tool into aliquid.
Ventilation slots can be cleaned using a dry, soft non-metallic
brush and/or a suitable vacuum cleaner. Do not use water or
any cleaning solutions. Wear approved eye protection and an
approved dustmask.
Sprocket and Sprocket Cover (Fig. A, H, I)
CAUTION: Sharp chain. Always wear protective gloves when
handling the chain. The chain is sharp and can cut you when it is
notrunning.
WARNING: Sharp moving chain. To prevent accidental
operation, ensure the battery is removed from the tool before
performing the following operations. Failure to do this could result
in serious personalinjury.
1. Place the saw on a flat, firmsurface.
2. Remove sprocket cover
17
as described in Installing the
Guide Bar and Saw Chainsection.
3. Wearing protective gloves, use a clean, soft bristle brush to
wipe away any saw dust, sticks, vines or other debris that may
have collected inside the sprocket cover
17
and around the
saw chain
16
or sprocket
42
.
4. Rotate the chain tension screw
19
using the flat screwdriver
end of thewrench
24
. Turning the screw counterclockwise
Saw Chain Sharpening (Fig. Z–BB)
CAUTION: Sharp chain. Always wear protective gloves when
handling the chain. The chain is sharp and can cut you when it is
notrunning.
WARNING: Sharp moving chain. To prevent accidental
operation, ensure that battery is removed from the tool before
performing the following operations. Failure to do this could result
in serious personalinjury.
WARNING: Do not over file chain rakers
56
, this will increase
the risk of kickback. If the chain
16
has been sharpened more than
four times, replaceit.
Each time the chain
16
is sharpened, it loses some of the low
kickback qualities and extra caution should beused.
It is recommended that a saw chain be sharpened no more
than fourtimes.
nOTE: The cutters
59
will dull immediately if they touch the
ground/dirt or a nail whilecutting.
To get the best possible performance from your pole saw it is
important to keep the cutters
59
of the saw chain sharp. Follow
these helpful tips for proper saw chain sharpening:
1. For best results use a 5/16" (4 mm) file and a file holder or
filing guide to sharpen your saw chain. This will ensure you
always get the correct sharpeningangles.
2. Place the file holder flat on the top plate
55
and depth
gauge of thecutter
59
.
3. Keep the correct top plate
55
filing angle line of 30°
57
on
your file guide parallel with your chain (file at 60° from chain
viewed from the side) as shownin Fig. Z.
4. Sharpen cutters
59
on one side of the chain
16
first. File
from the inside of each cutter to the outside. Then turn your saw
around and repeat the processes (2, 3, 4) for cutters on the other
side of thechain.
nOTE: Use a flat file to file the tops of the rakers
58
(portion
of chain link in front of the cutter
59
so they are about .025"
(.635mm) below the tips of the cutters as shownin Fig. AA.
5. Keep all cutter lengthsequal as shownin Fig. BB.
6. If damage is present on the chrome surface of the top
plates
55
or side plates
60
, file back until such damage
isremoved.
CAUTION: After filing, the cutter will be sharp, use extra
caution during thisprocess.
