5
ENGLISH
Impeller (Fig. F–K)
WARNING: To reduce the risk of serious personal injury,
turn unit off and remove the battery pack before making
any adjustments or removing/installing attachments or
accessories. An accidental start‑up can causeinjury.
CAUTION: Inspect the impeller for wear before each use.
Clear or replace the impeller if it appears blocked or damaged.
1. Using a crosshead screwdriver (not supplied), remove
the four impeller cover screws
9
from the impeller cover
8
by rotating them counterclockwise.
2. Lift the impeller cover from the pump housing.
3. Lift out the impeller window
21
.
4. Lift out the round impeller spacer
22
.
5. Pull the impeller
24
out from the pump housing
23
.
6. Pull the impeller o-ring
25
out from the pump housing.
7. Inspect impeller o-ring
25
and impeller
24
for wear and
damage. If there is any evidence of wear or damage, replace
the impeller or gasket with:
DeWALT impeller gasket NA304884.
DeWALT impeller NA379414.
8. Rinse off debris from the impeller o-ring
25
and
impeller
24
with clean water and a soft brush.
9. Apply a small amount (0.2-0.3 ml) of silicone grease
26
(not included) to the impeller blades
27
and the impeller
o-ring
25
and then install into the pump housing
23
as
shown in Fig. I, J.
10. Install the round impeller spacer
22
, the impeller
window
21
and then the impeller cover
8
over the
impeller. Insert the four impeller cover screws
9
into the
impeller cover
8
.
11. Using a crosshead screwdriver (not supplied) tighten
the four cover screws
9
clockwise until snug.
NOTE: Hand-tighten impeller cover screws. Do not use
power tools or overtighten.
MAINTENANCE
WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/installing
attachments or accessories. An accidental start‑up can
causeinjury.
Your DeWALT power tool has been designed to operate
over a long period of time with minimum maintenance.
Continuous satisfactory operation depends upon proper
tool care and regularcleaning.
OPERATION (Fig. A–E)
WARNING: To reduce the risk of serious personal injury,
turn unit off and remove the battery pack before making
any adjustments or removing/installing attachments or
accessories. An accidental start‑up can causeinjury.
CAUTION: Place the transfer pump on a dry, flat, and
stable surface only.
CAUTION: Keep the pump inlet clean and free of any
foreign objects and debris. Inspect the pump inlet, and the
outlet, at the beginning of each use.
CAUTION: Do not continuously run the pump for more
than onehour.
CAUTION: After usage, wear gloves prior to removing hose
fittings. Fittings maybe warm.
WARNING: Pumped water is not potable water and is
not safe for human or animal consumption.
WARNING: Never operate the pump without having a
hose connected to both inlet and outlet connections.
The DCE050 is equipped with a thermal sensor which avoids
overheating the pump. If the pump stops working and the LED
indicator is blinking red (refer to
LED Indicator Guide
), allow
the DCE050 to cool down before operating again. There is an
increased likelihood of thermal shutdown when trasfering
hotwater.
1. Arrange the inlet and outlet hoses to ensure that there
are no kinks or sharp bends.
2. Remove the two hose connection caps
10
.
3. Attach the inlet and outlet hoses to the transfer pump as
described in the Connecting Inlet and Outlet Hoses section.
4. Place the feet
3
or
4
on a dry, flat and stable surface.
5. Place the inlet
15
of the suction hose below the
watersurface.
6. Secure the free ends of both hoses
15
,
17
so they will
not move unexpectedly when the water transfer begins.
7. Install a battery pack
19
as described in the Installing
and Removing the Battery Pack section.
8. Press the on/off button
5
to power on the transferpump.
9. Allow at least tenseconds to purge the system of air. If the
pump doesn't prime and is still drawing air after tenseconds
press the on/off button
5
to turn the pump off.
CAUTION: DO NOT allow the pump to run dry. Damage
to the pump could occur. To help prevent pump damage, a
dry pump will shut off automatically within 60 seconds. Turn
the pump off and then back on to reset it.
GREEN LED
Unit is powered on. The LED indicator is constantly green.
BLINKING GREEN LED
Unit is powered on. The LED indicator is blinking green.
Battery charge is low. Remove the battery and charge it.
BLINKING RED LED
Unit is powered on. The LED indicator is blinking
red. The motor or battery is overloaded during
operation or has reached a high temperature. Allow
the DCE050 and the battery to cool down.
10. The pump should be no more than 15 ft (4.5 m) above
the inlet water source. The maximum recommended
discharge height is 45ft (13.7 m) above the pump.
NOTE: If anything but clear water is accidentally pumped,
flush the pump with clear water and/or a water/glycol mix
(up to 60% water and 40% glycol) for at least thirty seconds.
11. To stop pumping, press the on/off button
5
.
12. When finished pumping, remove the inlet and outlet
hoses and pour any excess water from the pump.
13. Remove any remaining water from the pump, run the
empty pump for no more than five seconds.
14. Install the two hose connection caps
10
to ensure
debris does not enter the pump while in storage.
CAUTION: Freezing temperatures can cause remaining
water in the pump to freeze and could damage the pump.
