05 GB
2.3. ADAPTING THE HOB TO DIFFERENT
TYPES OF GAS
To adapt the Hob for use with different types of gas, carry out the
following instructions:
•Remove the grids and burners
•Insert on hexagonal spanner (7 mm) into the burner support (Figure
7)
•Unscrew the injector and replace it with one suitable for the gas to be
used (see gas type table)
2.4. REGULATING THE MINIMUM FLAME
After lighting the burners, turn the control knob to the minimum setting
and then remove the knob (this can easily be removed by applying
gentle pressure).
Using a small «Terminal» type screwdriver the regulating screw can
be adjusted as in Figure 9. Turning the screw clockwise reduces the
gas flow, whilst turning it anticlockwise increases the flow – Use this
adjustment to obtain a flame of approximately 3 to 4 mm in length and
then replace the control knob.
When the gas supply available is LPG - the screw to set the idle flame
must be turned (clockwise) to the end stop.
When you have carried out the new gas regulation, replace the old gas
rating plate on your appliance with one (supplied with hob) suitable for
the type of gas for which it has been regulated.
3. USE OF HOB - USER INSTRUCTIONS
This appliance must only be used for the purpose for which it is
intended, domestic cooking, and any other use will be considered
improper and could therefore be dangerous. The Manufacturer will
not be responsible for any damage or loss resulting from improper
use.
2)Tighten the joints with the spanner, remembering to twist the
pipes into position.
3)Attach fitting C to mains gas supply using rigid copper pipe or
flexible steel pipe.
IMPORTANT: carry out a final check for leaks on the pipe
connections using a soapy solution. NEVER USE A FLAME.
Also, make sure that the flexible pipe cannot come into contact
with a moving part of the cabinet (eg.adrawer) and that it is not
situated where it could be damaged.
Warning: If gas can be smelt in the vicinity of this appliance turn off
the gas supply to the appliance and call the engineer directly. Do not
search for a leak with a naked flame.
Before using burner, be sure, grid perimeters center the burner as
below figure.
If you are using Cast Iron Grids; underneath the grid, position of it is
stated. Be sure for the exact grid is used in correct position.
Table A
Burner Type
Ø pan/pot
(cm)
AUX
SR
R
10 - 18
12 - 22
16 - 26
Auxlary
Sem Rapd
Rapd
Power
(kW)
1,00
1,75
2,70
G20/20 mbar
(methane)
95 l/h
167 l/h
257 l/h
G30/28-30 mbar
(LPG)
73 g/h
127 g/h
196 g/h
3.1. USING THE GAS BURNER
To gnte the burners, for appliances fitted with electric ignition and
safety valve system, carry out the following:
• WARNING:Prior to switching on the gas hob ensure that the burners
and burner caps are correctly placed within their position.
• Push in and turn the knob anticlockwise to the ignition star symbol ( )
• The ignition system will continue to generate sparks as long as the
control knob is being pressed.
• If the burner has not ignited within 5 seconds, turn the knob to the
(off) position and repeat the operation.
• Warning: In the case of a mains failure light the burner with a match
or lighted taper: place the match or lighted taper close to the burner,
press in and turn the control knob anticlockwise to the ignition star
symbol ( ).
• Wait for a few seconds after the gas burner has been lit before letting
go of the knob (valve activation delay).
• After having completed the ignition procedere, adjust the gas valve
to the desired position.
The appliance has a safety valve system fitted, the flow of gas will be
stopped if and when the flame should accidentally go out.
If the burner flame should go out for some reason, the safety valve will
automatically stop the gas flow.To re-light the burner, return the knob
to the closed (off) position, wait for at least 1 minute and then
repeat the lighting procedure.
GENERAL ADVISE
For best results, use cooking vessels with a flat surface. The size of
the surface should match the gas burner size as follows. Table A.
4. MAINTENANCE AND CLEANING
Before cleanng the hob, ensure the applance has cooled down.
Remove the plug from the socket or (f connected drectly) swtch off
the electrcty supply.
Cleanng and user mantenance shall not be made by chldren wthout
supervson
Never use abrasves, corrosve detergents, bleachng agents or
acds. Avod any acd or alkalne substances (lemon, juce, vnegar
etc.) on the enamelled, varnshed or stanless steel sectons.
When cleanng the enamelled, varnshed or chrome sectons, use
warm soapy water or a non caustc detergent. For stanless steel use
an approprate cleanng soluton.
The burners can be cleaned wth soapy water. To restore ther orgnal
shne, use a household stanless steel cleaner. After cleanng, dry the
burners and replace.
It s mportant the Burners are replaced correctly.
Chromed grds and burners
Chromed grids and burners have a tendency to discolour with use.
This does not jeopardize the functionality of the hob.
Our After Sales Service Centre can provide spare parts if required.
For smaller contaners the gas burner should be regulated so that the
flame does not overlap the base of the pan. Vessels wth a concave or
convex base should not be used.
WARNING: If a flame s accdentally extngushed, turn the knob
to the off poston and do not attempt to re-gnte f for at least 1
mnute.
If over the years the gas taps become stff to turn t s necessary to
lubrcate them.
Such operaton must be carred out only by qualfed Servce
Engneers.
