3
8
Installation instructions
Cavity preparation
IMPORTANT!
The power outlet must be located
in a cabinet adjacent to the
dishwasher cavity.
Services can be located either
side of the dishwasher.
Ensure that any services hole has
a minimum diameter of 50mm.
Positioning and stabilising the dishwasher
Do not lift the dishwasher from the door handle.
As you push product in, pull through hoses and cord, ensuring they don’t get kinked or twisted.
Plastic spacers can now be inserted at the side of the dishwasher next to the hinge to improve
stabilitysee step 7 for details on fitting spacers
After sliding the dishwasher into position, adjust back foot with a 6mm Allen key.
The front feet can be adjusted manually also.
We recommend that you adjust the feet so that the dishwasher sits securely under the
bench top so that it doesn’t tip.
Dia. 50mm
Apply moisture protection
tape to the underside
of the benchtop.
IMPORTANT!
To prevent possible steam damage to the cabinetry, ensure that any bare wood surrounding
the dishwasher is sealed with an oil-based paint or moisture-proof polyurethane.
1
3
4
2
Back foot of the
dishwasher can be
adjusted by using
a 6mm Allen key
(not supplied)
Front feet of
dishwasher can
be adjusted as
shown
