Je bekijkt pagina 8 van 88

7

DESCRIPTION OF APPLIANCE

A Top heating element

B Inside light (certain models only)

C Wire rack – (*) Certain models only

D Bake pan (certain models only)

E Thermostat dial

F Timer dial

G Function selector dial

H Thermostat light

I Bottom heating element

L Glass door

M Crumb tray

TECHNICAL DATA

Voltage: 220-240 V ~ 50/60Hz

Absorbed power: 1400 W

Size LxHxD: 490 x 235 x 370 mm

Weight: 8.3 kg

FUNCTIONS

GRILL FUNCTION ideal for grilling food

TRADITIONAL OVEN FUNCTION ideal for all types of

traditional cooking

DEFROSTING FUNCTION ideal for defrosting all products

(certain models only)

CONVECTION ideal for quicker more even cooking

(certain models only)

KEEPING FOOD WARM

Please note: For more information regarding the various

functions and cooking tables, refer to the images on page 73-81.

THERMOSTAT LIGHT

The thermostat light (H) lights when the oven is on and turns o

when the oven reaches the set temperature.

IMPORTANT SAFEGUARDS

Read all the instructions carefully before using the ap-

pliance. Keep these instructions.

Please note:

This symbol identies important advice or information for the

user.

• Beforeusingtheovenforthersttime,removeanypaper

and other material inside the oven such as protective card-

board, booklets, plastic bags, etc.

• Theappliancemustbekeptatadistanceofatleast20cm

from the mains power socket to which it is connected.

• Beforeusing for the rst time,operatetheovenempty

with the thermostat at maximum for at least 20 minutes

to eliminate the “new” smell and any smoke caused by the

presence of protective substances applied to the heating

elements before transport. Ventilate the room.

• Washallaccessoriesbeforeuse.

• Neverusecorrosiveoracidoraggressivedetergenttoclean

the oven cavity or the accessories.

Important!

Failure to observe the warning could result in injury or damage

to the appliance.

• Thisovenisdesignedtocookfood.Itmustneverbeused

for other purposes, modied or tampered with in any way.

• Afterunpackingtheappliance,makesurethedoorisun-

damaged and working correctly.

The door is made from glass and is therefore fragile. If it is

visibly chipped, scored or scratched, it should be replaced.

While using, cleaning or moving the appliance, avoid

slamming or knocking the door violently. Do not pour cold

liquid onto the glass while the appliance is hot.

• Placetheapplianceonahorizontalsurfaceataheightofat

least 85 cm and out of reach of children.

• This appliance can be used by children

aged from 8 years and above and per-

sons with reduced physical, sensory or

mental capabilities or lack of experience

and knowledge if they have been given

supervision or instruction concerning

use of the appliance in a safe way and

understand the hazards involved. Chil-

dren should be supervised to ensure that

they do not play with the appliance.

Cleaning and user maintenance shall

not be made by children, unless they

are more than eight years old and under

constant supervision.

• Keep the appliance and power cable

away from children under eight years of
