CONVERSION TO NATURAL GAS OR TO LPG
REPLACEMENT OF THE INJECTORS
If the injectors are not supplied they can
be obtained from the
After-Sales Service.
Select the injectors to be replaced
according to the “Table for the choice of the
injectors”.
The nozzle diameters, expressed in
hundredths of a millimetre, are marked on
the body of each injector.
REPLACEMENT OF THE INJECTORS
OF THE COOKTOP BURNERS
To replace the injectors proceed as follows:
• Remove pan supports and burners
from the cooktop.
• Using a wrench, substitute the nozzle
injectors “J´ ¿JV D E ZLWK
those most suitable for the kind of gas
for which it is to be used.
The burners are conceived in such a
way so as not to require the regulation
of the primary air.
ADJUSTING OF THE MINIMUM OF
THE TOP BURNERS
,Q WKH PLQLPXP SRVLWLRQ WKH ÀDPH PXVW
have a length of about 4 mm and must
remain lit even with a quick turn from the
maximum position to that of minimum.
7KH ÀDPH DGMXVWPHQW LV GRQH LQ WKH
following way:
• Turn on the burner.
• Turn the tap to the MINIMUM position.
• Take off the knob.
• With a thin screwdriver turn the screw
“A´XQWLODGMXVWPHQWLVFRUUHFW¿JF
Normally for LPG, tighten up the
regulation screw.
Fig. 2.5a
J
Auxiliary,
Semi-rapid and
Rapid burners
Fig. 2.5c
A
Double-ring compact
burner
J
Fig. 2.5b
