EN - 19
4. USE OF PRODUCT
4.1 uSe of GaS burnerS
Ignition of the burners
The position symbol above each control
knob indicates the burner that the knob
controls.
Manual ignition of the gas burners
If your appliance is not equipped with an
ignition aid, or if there is a failure in the
electric network, follow the procedures
listed below.
For hob burners: Push in the knob of
the burner you wish to ignite and keep it
pressed while turning it anticlockwise until
the knob is in the ‘max’ position. Continue
pressing the knob and hold a lit match,
taper or other manual aid to the upper
circumference of the burner. Move the
ignition source away from the burner as
soon as you see a stable flame.
Electrical ignition by spark button
Push in the knob of the burner you wish
to ignite and keep it pressed while turning
it anti-clockwise until the knob is in the
'maximum' position. While keeping the
knob pressed in, push the ignition button.
Make sure that you press the ignition button
immediately as a delay could cause a build
up of gas which may result in the flame
spreading. Continue pressing the ignition
button until you see a stable flame on the
burner.
Flame safety device
Hob burners
Hobs equipped with a flame failure device
provide security in case of an accidentally
extinguished flame. For this reason, during
ignition, keep the knob pressed until you
see stable flames.
Hold down the control for approximately
10 to 15 seconds after the burner has
lit. Releasing the control too soon will
extinguish the flame.
If such a case occurs, the device will block
the burners gas lines and will avoid any
accumulation of unburned gas. Wait 90
seconds before re-igniting an extinguished
gas burner.
4.2
hob ControlS
Hob burner
The knob has 3 positions: off (0), maximum
(big flame symbol) and minimum (small
flame symbol). Ignite the burner with the
knob in the 'maximum' position; you can
then adjust the flame length between the
'maximum' and 'minimum' positions. Do
not operate the burners when the knob is
between the 'maximum' and 'off' positions.
OFF position
MAX position
MIN. position MODULATE
After ignition, visually check the flames.
If you see a yellow tip, lifted or unstable
flame, switch the gas flow off, then check
the assembly of burner caps and crowns
once they have cooled. Make sure there is
no liquid in the burner caps. If the burner
flames go out accidentally, switch the
burners off, ventilate the kitchen with fresh
air and wait at least 90 seconds before
attempting re-ignition.
Cap
Crown
Spark
plug
Burner
cup
To switch the hob burners off, turn the hob
burner knob clockwise to the ‘0’ position or
so that the marker on the hob burner knob
points upwards.
Your hob has burners of different diameters.
You will find that the most economical
way of using gas is to choose the correct
size gas burner for your cooking pan size
and to bring the flame to the 'minimum'
position once boiling point is reached. We
recommend that you always cover your
cooking pan to avoid heat loss.
To obtain maximum performance from the
main burners, we suggest you use pots with
