Setting up the monitor | 33
To remove the VESA cover:
Press the dimple on the VESA cover to release it from the back of the display.
Wall mounting (optional)
NOTE: Use M4 x 10 mm screws to secure the wall-mounting kit to the
monitor.
NOTE: The wall-mounting kit is sold separately.
See the documentation that is shipped with the VESA-compatible wall mounting kit.
1. Place a at cushion or a sitting mat near the edge of a table and place the
monitor on it with the display facing down.
2. Remove the stand.
3. Using a Phillips crosshead screwdriver, remove the four screws that secure the
back panel to the main chassis.
4. Connect the mounting bracket from the wall mounting kit to the monitor.
5. Follow the instructions that shipped with the wall-mounting kit and mount the
monitor on the wall.
NOTE: For use only with UL or CSA or GS-listed wall mount bracket with
minimum weight/load bearing capacity of 11.60 kg (SE2422H)/13.80 kg
(SE2422HX).
