10 | About your monitor
Bottom view
1 2 3 456 788
Label Description Use
1 Security-lock slot Secures monitor with security cable lock (sold
separately).
2 Power connector Connect the power cable (shipped with your
monitor).
3 HDMI port Connect your computer with the HDMI cable.
4 USB-C port
(Video + Data)
Connect to your computer using the USB-C cable.
The USB-C port offers the fastest transfer rate
(USB 3.2 Gen 1). The alternate mode with DP 1.2
supports the maximum resolution of 1920 x 1080
at 75 Hz and PD 20 V/3.25 A, 15 V/3 A, 9 V/3 A,
5 V/3 A.
NOTE: USB-C is not supported on Windows
versions that are prior to Windows 10.
5 Audio line-out port Connect speakers to playback audio through
HDMI or USB-C audio channels.
Only two-channel audio is supported.
NOTE: The audio line-out port does not support
headphones.
6 USB 3.2 downstream
port
Connect the USB-C cable that comes with your
monitor to the computer. Once this cable is
connected, you can use the USB downstream
connectors on your monitor.
Port supports 0.9 A.
7 USB 3.2 downstream
port
Connect the USB-C cable that comes with your
monitor to the computer. Once this cable is
connected, you can use the USB downstream
connectors on your monitor.
Port supports Battery Charging 2 A.
8 Built-in speakers To output the sound from audio input.
