16
About your monitor
Electrical specifications
Table 15. Electrical specifications.
Description P3225DE P3225QE
Video input signals Digital video signal for each differential line per differential line at 100 ohm impedance
DP/HDMI/USB-C signal input support
Input voltage/frequency/current 100-240 VAC/50 Hz or 60 Hz ± 3 Hz/2.8 A (typical)
Inrush current 120 V: 42 A (maximum)
240 V: 80 A (maximum)
Inrush current is measured at an ambient temperature of 0°C (cold start.).
Power consumption 0.3 W (Off Mode)
1
0.4 W (Standby Mode)
1
0.8 W (Networked standby Mode)
1
23.1 W (On Mode)
1
192 W (maximum)
2
20.8 W (P
on
)
3
66.5 kWh (TEC)
3
0.3 W (Off Mode)
1
0.4 W (Standby Mode)
1
0.8 W (Networked standby Mode)
1
27.8 W (On Mode)
1
205 W (maximum)
2
25.2 W (P
on
)
3
81 kWh (TEC)
3
1
As defined in EU 2019/2021 and EU 2019/2013.
2
Maximum brightness and contrast setting with maximum power loading on all USB ports.
3
P
on
: Power consumption of On Mode as defined in Energy Star 8.0 version.
TEC: Total energy consumption in kWh as defined in Energy star 8.0 version.
This document is informational only and reflects laboratory performance. Your product may perform differently, depending on the
software, components, and peripherals you have ordered and Dell has no obligation to update such information. Accordingly, the
customer should not rely upon this information in making decisions about electrical tolerances or otherwise. No warranty as to
accuracy or completeness is expressed or implied.
NOTE: This monitor is ENERGY STAR certified. .
This product qualifies for ENERGY STAR in the factory default settings which can be restored by Factory Reset function in the OSD
menu. Changing the factory default settings or enabling other features may increase power consumption that could exceed the
ENERGY STAR specified limit.
Physical characteristics
Table 16. Physical characteristics.
Description P3225DE P3225QE
Signal cable type DP to DP cable (1.80 m)
USB-C to C 10Gbps 100 W cable (1.0 m)
USB Type-C to Type-A 5Gbps 15W cable (1.80 m)
Dimensions (with stand)
Height (extended) 619.00 mm (24.37 in.) 619.00 mm (24.37 in.)
Height (compressed) 469.00 mm (18.46 in.) 469.00 mm (18.46 in.)
Width 713.40 mm (28.09 in.) 713.40 mm (28.09 in.)
Depth 215.00 mm (8.46 in.) 215.00 mm (8.46 in.)
Dimensions (without stand)
Height 413.15 mm (16.27 in.) 413.15 mm (16.27 in.)
Width 713.40 mm (28.09 in.) 713.40 mm (28.09 in.)
Depth
49.95 mm (1.97 in.) 49.95 mm (1.97 in.)
Stand dimensions
Height (extended)
483.30 mm (19.03 in.) 483.30 mm (19.03 in.)
Height (compressed)
436.42 mm (17.18 in.) 436.42 mm (17.18 in.)
Width
287.50 mm (11.32 in.) 287.50 mm (11.32 in.)
Depth
215.00 mm (8.46 in.) 215.00 mm (8.46 in.)
Base 287.50 mm x 215.00 mm
(11.32 in. x 8.46 in.)
287.50 mm x 215.00 mm
(11.32 in. x 8.46 in.)
Weight
Weight with packaging 12.90 kg (28.44 lb) 12.94 kg (28.53 lb)
