Setting up the monitor 41
Connecting your monitor
WARNING: Before you begin any of the procedures in this section, follow the Safety instructions.
WARNING: For your safety, be sure that the grounded power outlet you plug the power cable into is easily accessible to the
operator and located as close to the equipment as possible.
To disconnect power from the equipment, unplug the power cable from the power outlet by grasping the plug firmly. Never
pull on the cord.
WARNING: A certified power supply cable has to be used with this equipment. The relevant national installation and/or
equipment regulations shall be considered. A certified power supply cable not lighter than ordinary polyvinyl chloride flexible
cord according to IEC 60227 (designation H05VV-F 3G 0.75 mm² or H05VVH2-F2 3G 0.75 mm²) shall be used. An alternative
flexible cord is synthetic rubber.
NOTE: Do not connect all cables to the computer at the same time. It is recommended to route the cables through the cable-
management slot before you connect them to the monitor.
NOTE: Dell monitors are designed to work optimally with Dell-supplied inbox cables. Dell does not guarantee the video quality
and performance if non-Dell cables are used.
NOTE: Route the cables through the cable-management slot before connecting them.
NOTE: The graphics are used for the purpose of illustration only. The appearance of the computer may vary.
To connect your monitor to the computer:
1. Turn off your computer and disconnect the power cable.
2. Connect the DisplayPort, HDMI, or Type-C cable from your monitor to the computer.
3. Switch on your monitor.
4. Select the correct input source at the monitor OSD Menu and turn on your computer.
Connecting HDMI cable (optional)
HDMI
HDMI
Figure 26. Connecting HDMI cable
Connecting DisplayPort (DisplayPort to DisplayPort) cable
DP
DP
Figure 27. Connecting DisplayPort cable
