About your monitor 13
Rear and bottom view
P2725D
1 2 3 4 5 6 7 89
Figure 4. Bottom view without monitor stand
Table 6. Components and descriptions.
Label Description Use
1 Security-lock slot
(based on Kensington Security Slot)
Secure your monitor using a security lock (purchased separately) to prevent
unauthorized movement of your monitor.
2 Power connector Connect the power cable (shipped with your monitor).
3 Stand-lock feature Lock the stand to the monitor using a M3x6 mm screw (screw not included).
4 HDMI port Connect your computer with the HDMI cable.
5 DisplayPort Connect your computer with the DisplayPort cable.
6 USB 5Gbps Type-B upstream port Connect the USB cable that came with your monitor to the computer. Once
this cable is connected, you can use the USB connectors on the monitor.
7 USB 5Gbps Type-A downstream port
Port with
icon supports 5 V/0.9 A.
Connect your USB device. You can use these ports only after you have
connected the USB cable from the computer to the monitor.
NOTE: To avoid signal interference, when a wireless USB device has
been connected to a USB downstream port, it is not recommended to
connect any other USB devices to the adjacent ports.
8 Pop out QuickAccess port For more information, see Front view.
9 Soundbar slots Attach your external Soundbar (sold separately) to the monitor by aligning
the magnetic tabs on the soundbar with the slots on the monitor.
